The RHW1800 is a 3 speed hand winch that allows for optimum performance with minimal effort.
Position the handle to suit the load and wind speed required.
Features:
- Compact design.
- Formed reinforcements in frame for added frame strength
- Very low torque required for ease of operation
- One way Ratchet. Free spool in off direction.
- High quality one piece hardened steel gears.
- Superior finish quality for appearance and corrosion resistance.
- Extensively tested and QA inspected.
- 3 winding positions to give the speed and torque required for the job.
- Standard winch is supplied without cable or strap.
Models with cable or strap available to order.
| Specifications | |
| Part No | AL01509 - WINCH ONLY |
| Ratio 1 - 1:1 |
204Kg / 450lb |
| Ratio 2 - 4.6:1 |
500Kg/1100lb |
| ratio 3 - 9.7:1 |
817Kg/1800lb |
| Handle force | under 200 (N) |
| Weight | 6.3 |
| Cable | 5.56mm x 15m |
| Single package. | 31x21.5x18.6 |
| Full carton - 4 pcs | 46x34x39 - 24 Kg |
